The AIRAID Throttle Body Spacer is designed to enhance mid-range torque using a patented Helix Bore which spins intake air going through the throttle body spacer. Includes mounting hardware.
The AIRAID Throttle Body Spacer is designed to enhance off-idle torque from 800 rpm to approximately 3,000 rpm. The spacer utilizes it's unique, patented Helix Bore design to spin the incoming air charge as it passes through the throttle body spacer. The spinning air action boosts the velocity of the incoming air and contributes to better atomization of the air/fuel mixture as the air charge enters the combustion chamber. The end result is more part-throttle torque and improved mid-range power.
- Made from aircraft quality billet 6061-T6 aluminum
- Improves low end torque and throttle response
- Gaskets, hardware and precision brackets are included
- Installs in less than 1 hour
- No drilling or cutting required
- Provides stronger mid-range power
Application Summary:
| Year |
Make/Model |
| 2007-2013 |
Cadillac Escalade |
| 2007-2013 |
Cadillac Escalade ESV |
| 2007-2013 |
Cadillac Escalade EXT |
| 2007-2013 |
Chevrolet Avalanche |
| 2007-2013 |
Chevrolet Silverado 1500 |
| 2007 |
Chevrolet Silverado 1500 Classic |
| 2007 |
Chevrolet Silverado 1500 HD Classic |
| 2007-2013 |
Chevrolet Suburban 1500 |
| 2007-2013 |
Chevrolet Tahoe |
| 2009 |
Chevrolet Trailblazer |
| 2013 |
GMC Sierra |
| 2007-2013 |
GMC Sierra 1500 |
| 2007 |
GMC Sierra 1500 Classic |
| 2007 |
GMC Sierra 1500 HD Classic |
| 2007-2013 |
GMC Yukon |
| 2007-2013 |
GMC Yukon XL 1500 |
| 2007-2011 |
GMC Yukon XL 2500 |
| 2013 |
GMC Yukon XL 2500 |
| Attributes |
| ASIN |
B000Z7D1FO |
| Alternate Part Number |
AIR-200-617 |
| CARB EO Number |
D-609-10, D-609-10 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
CN |
| Emission Code |
Legal US |
| Finish |
Black |
| GTIN |
00642046206178 |
| Gasket Or Seal Included |
Yes |
| Gaskets Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8481909010 |
| Hazardous Material Code |
N |
| Item Weight |
1.200 lbs. (0.5 kg) |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum |
| Material Used |
Aluminum, Aluminum |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Package Material |
Plastic Other |
| Package Type |
Blisterpack |
| Product Box Height |
9.75 in (248 mm), 9.750 in. (248mm) |
| Product Box Length |
6 in (152 mm), 6.000 in. (152mm) |
| Product Box Width |
1.5 in (38 mm) |
| Product Style |
AIRAID PowerAid, AIRAID PowerAid |
| SDR Required Flag |
N |
| Spacer Type |
4-Barrel Open |
| Street Legal In All US States |
See Application Link Above, Not legal for sale or use in California on any pollution controlled motor vehicle. NOTE: Some specific models and years may be legal in CA. Check the CARB status on your parts at knfilters.com. |
| TUV Approved (Europe) |
No, No |
| Thickness |
1 in (25 mm), 1 in (25 mm) |
| Warranty |
12 Months - 24,000 Miles |
| Weight |
1.2 lb (0.5 kg), 1.2 lb (0.5 kg) |
